1000W Class D 4 Channel Full Range Mini Amplifier

Full Range Class D Amplifier

• 4 Channel Full Range Class D Technology
• 2-Ohms Stereo load Capability
• Marine grade conformal coating on PCB
• Audiophile Grade RCA connectors
• Variable 12db High/Low-pass crossover filters
• Bridgeable outputs @ 4-Ohms load
• Double Sided Circuit tablet
• Compatible with any 4/2-Ohms Loudspeaker
• Output Power @ 14.4 VDC, 4-Ohms 4 x 125W
• Output Power @ 14.4 VDC, 2-Ohms 4 x 250W
• Output Power @ 14.4 VDC, Bridge 2 x 500W
• Power Supply Input Voltage 12.0VDC to14.8VDC
• TTHD (1kHz @ 4-Ohms): 0.04%
• Bandwidth (-3 dB): 18Hz - 22KHz
• Damping Factor (1k Hz @ 4-Ohms): 100
• S/N ratio ( as weighted @ 1 Volt): 99db
• Input Sensitivity: .20V - 5.0V RMS
• Minimum Load Impedance: 2-Ohms
• Input Pre in RCA
• Channel 1-2 filter range: 55Hz - 750Hz
• Channel 3-4 filter range: 55Hz - 750Hz
• Variable Bass Boost: 45Hz @ 0 ~ 12dB

This powerful amplifier delivers clear, crisp sound even in the harshest marine environments. With its powerful 1000W peak power and 2Ω mono load capability, this amplifier can easily drive even the most demanding speakers. The Class D circuitry ensures that the amplifier delivers clean, accurate sound, while the marine grade components help to keep the amplifier cool even under heavy loads. The 1000W Class D 4 Channel Full Range Mini Amplifier also features a variety of features that make it easy to use and customize, including a variable low pass crossover, bass boost, and sub-sonic filter.

Benefits:

Powerful sound
Reliable construction
User-friendly features

Order your 1000W Class D 4 Channel Full Range Mini Amplifier today and experience the difference!

Here are some additional details about the 1000W Class D 4 Channel Full Range Mini Amplifier:

Class D amplifiers are known for their high efficiency and low power consumption. This makes them ideal for use in marine applications, where space and weight are often limited.
2Ω Mono Load Capability: The 1000W Class D 4 Channel Full Range Mini Amplifier can be used with a single subwoofer that has an impedance of 2Ω. This allows for maximum power output and the best possible sound quality.
Rated Power @14.4VDC, 4Ω 4x125 Watts: The 1000W Class D 4 Channel Full Range Mini Amplifier is rated to output 125 watts of power at 14.4 volts per channel. This means that it can easily drive even the most demanding speakers.
Marine Grade Nickel Plated RCA Connectors: The marine grade nickel plated RCA connectors are corrosion resistant and provide a reliable connection between the amplifier and your source unit.
Variable 12dB Low-Pass Crossover: The variable 12dB low-pass crossover allows you to adjust the crossover frequency of the amplifier. This is important for ensuring that the speakers are playing at the right frequency and not interfering with each other.
Order your 1000W Class D 4 Channel Full Range Mini Amplifier today and experience the difference!
